Reading time: ca. 5 min. | An article from Application Engineering | TUNAP Blog
Special Oils for Different Applications
High-temperature special oils are used in many different industrial applications: on conveyor belts and chains in drying ovens for gypsum and insulation material manufacturing as well as in the packaging, food, coating and glass container industries.
The Following Performance Requirements are Extremely Important:
- Optimum friction and wear reduction under mixed friction conditions for reliable machine operation and long component service life.
- Low tendency to form coating residues in order to guarantee fault-free re-lubrication of the friction points.
- High penetration and wetting ability for the best possible lubrication of crucial friction points.
- Excellent adhesion in the friction points to prevent oil dripping and being spun off and, consequently, being carried over to other areas.
- Low evaporation losses for economical use and clean production facilities.
Often, some of these aspects are conflicting: they have to be carefully considered and coordinated especially with regard to the respective application requirements to achieve optimum component service life.
Extensive Portfolio of Special Oils for High-Temperature Applications
TUNAP offers a complete range of special high-performance oils for conveying systems and glass machines in various high-temperature applications. Below is an overview of our high-temperature special oils with their respective areas of application and specific properties:
TUNFLUID HTFG 100 and TUNFLUID HTFG 260
Area of Application
- Synthetic high-temperature oils for chain lubrication in the food processing industry
- Registration: NSF H1
Added Value
- Extremely economical with regard to consumption due to high thermal stability with extremely low evaporation loss to approx. +250 °C
- NSF H1 registration for heightened product and process reliability
- Very clean to use, especially at very high temperatures due to low residue formation
TUNFLUID HTC 100 and TUNFLUID HTC 260
Area of Application
- Synthetic high-temperature oils for chain lubrication
Added Value
- Very economical with regard to consumption due to high thermal stability with extremely low evaporation loss to approx. +240 °C
- Clean to use, since even at high operating temperatures no coating residues are formed
TUNFLUID HTG 200
Area of Application
- Special oil to lubricate glass container machines
- Registration: NSH H2
Added Value
- Economic to use, e.g. on Emhart-IS machines
- Outstanding wear protection for reliable machine operation and low reject rates
- NSF H2 registration for heightened product and process reliability NSF H2
TUNFLUID LT 220
Area of Application
- Synthetic special oil for chain and cable lubrication for use in a wide range of temperature
Added Value
- Many different uses in high and low temperature applications thanks to the wide range of temperatures
- Energy saving due to special friction reduction through innovative OMC2 technology
TUNFLUID HT 200
Area of Application
- High-temperature oil with OMC2 wear protection technology
Added Value
- Very economical with regard to consumption due to high thermal stability with extremely low evaporation loss to approx. +220 °C
- Energy saving due to special friction reduction through innovative OMC2 technology
TUNFLUID HT 2200
Area of application
- Strong adhesive high-temperature oil with OMC2 wear protection technology
Added value
- Very economical with regard to consumption due to high thermal stability with extremely low evaporation loss to approx. +230 °C
- Energy saving due to special friction reduction through innovative OMC2 technology
